Orange Pi 5 Plus

The Orange Pi 5 Plus features the Rockchip RK3588 8-core 64-bit processor. Comprising a quad-core A76 and quad-core A55 configuration. With its 8nm process design, the processor operates at a maximum frequency of 2.4GHz. It incorporates the ARM Mali-G610 GPU with a built-in 3D GPU, supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.2, and Vulkan 1.2. Additionally, it boasts an embedded NPU capable of INT4/INT8/INT16/FP16 mixed computing, delivering up to 6Tops of computing power. This level of performance effectively caters to the edge computing requirements of most end devices. The Orange Pi 5 Plus is equipped with 4GB, 8GB, or 16GB LPDDR4/4x memory options and an eMMC socket, facilitating connection with 16GB, 32GB, 64GB, 128GB, or 256GB eMMC modules. In terms of operating systems, the Orange Pi 5 Plus offers compatibility with Orange Pi OS, the official operating system developed by Orange Pi. It also supports Android 12, Debian 11, Ubuntu 22.04, and various other operating systems.

Hardware Parameters:

SoC	Rockchip RK3588 (8nm LP process)
CPU	- 8-core 64-bit processor - 4 x Cortex-A76(2.4GHz), 4 x Cortex-A55(1.8GHz) and separate NEON co-processors
GPU	- Arm Mali-G610 - Built-in 3D GPU - Compatible with OpenGL ES1.1/2.0/3.2, OpenCL 2.2 and Vulkan 1.2
NPU	Embedded NPU supports INT4/INT8/INT16/FP16 mixed operation, with up to 6Tops computing power
PMU	RK806-1
RAM	4GB/8GB/16GB （LPDDR4/4x）
Memory	- QSPI Nor FLASH: 16MB/32MB - MicroSD card slot: up to 128GB - eMMC socket: 16GB/32GB/64GB/128GB/256GB eMMC module can be attached - M.2 2280 slot for NVMe SSDs (PCIe 3.0 x4) up to 2,000 MB/s
USB	USB3.0 x 2 USB2.0 x 2 Type-C x1
Video	- 2x HDMI 2.1 out up to 8k@60FPS - 1x Type-C with DP TX 1.4A，up to 8K@30FPS - 1x HDMI in with up to 4K@60FPS - 1 x MIPI DSI TX 4 Lane，up to 4K @60Hz
TP interface	1x 6Pin FPC socket
Camera	- 1XMIPI CSI 4 Lane
Audio	CODEC:ES8388 - 1xAudio 3.5mm jack with mic - 1xMIC In - 1xHDMI 2.1 eARC - 1xSPK
Ethernet	2xPCIe 2.5G LAN（RTL8125BG)
Expansion Port	40Pin dual row pins with the following multiplexing functions: UART, I2C, SPI, CAN, I2S, PDM, AUDDSM, SDIO, PWM, GPIO
PCIe M.2 M-KEY Socket	M.2 connector M key (bottom) for NVMe with PCIe 3.0 x4 lanes 2280 SSD
PCIe M.2 E-KEY Socket	M.2 connector E key (top) for connectivity with PCIe 2.0 x1/PCM/UART/USB2.0,2230 Wi-Fi6 /BT supported
Button	1xMaskROM key 1xRecovery 1xon/off key
Power Source	Support Type-C power supply, 5V@4A
IR receiver	1x IR receiver tube
LED	RGB LED side light
FAN	5V FAN
RTC	2Pin: RTC backup battery
Debugging	3Pin debug serial port (UART)
Supported OS	Orangepi OS(Droid)Orangepi OS(Arch) Ubuntu22.04 Debian11 Android12
